- General Information
- Manufacturer
- ASRock, Inc
- Manufacturer Website Address
- http://www.asrock.com
- Brand Name
- ASRock
- Product Type
- Gaming Desktop Motherboard
- Processor & Chipset
- Chipset Manufacturer
- AMD
- Chipset Model
- WRX80
- Total Processor Supported
- 1
- Processor Socket
- Socket sWRX8
- Processor Supported
- Ryzen Threadripper PRO
- Memory
- Number of Memory Slots
- 8
- Memory Form Factor
- UDIMM
- DIMM
- RDIMM
- Maximum Memory Supported
- 2 TB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 4400 MHz
- 3200 MHz
- 2933 MHz
- 2667 MHz
- 2400 MHz
- 2133 MHz
- I/O Controller
- Controller Type
- Serial ATA
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 10
- Video
- Onboard Video
- CPU Dependent Video
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Bluetooth
- Yes
- Bluetooth Standard
- Bluetooth 5.3
- 10Gigabit Ethernet
- Yes
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11 a/b/g/n/ax
- I/O Expansions
- PCI Express Standard
- PCI Express 4.0
- Total Number of PCI Express Slots
- 7
- Number of PCI Express x16 Slots
- 7
- Interfaces/Ports
- Total Number of USB Ports
- 3
- Number of USB 2.0 Ports
- 1
- Number of USB 3.2 Ports
- 4
- Number of USB 3.2 Gen 1 Ports
- 2
- S/PDIF
- Yes
- VGA
- Yes
- DisplayPort
- Yes
- Number of Network (RJ-45) Ports
- 3
- Onboard Interfaces
- Number of SATA Interfaces
- 8
- Number of M.2 Interfaces
- 2
- Total Number of Onboard USB Ports
- 1
- Number of Onboard USB 3.2 Ports
- 1
- Physical Characteristics
- Form Factor
- Extended ATX
- Width
- 304.8 mm
- Depth
- 271.8 mm
