- General Information
- Manufacturer
- ASRock, Inc
- Manufacturer Website Address
- http://www.asrock.com
- Brand Name
- ASRock
- Product Type
- Desktop Motherboard
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- Z590
- Total Processor Supported
- 1
- Processor Socket
- Socket LGA-1200
- Processor Supported
- Celeron
- Core i3
- Core i5
- Core i7
- Core i9
- Pentium Gold
- Multi GPU Supported
- CrossFireX
- Memory
- Number of Memory Slots
- 2
- Memory Form Factor
- DIMM
- UDIMM
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 6000 MHz
- 5000 MHz
- 3200 MHz
- 2933 MHz
- Intel Optane Memory Ready
- Yes
- I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 10
- Video
- Onboard Video
- CPU Dependent Video
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Bluetooth
- Yes
- Gigabit Ethernet
- Yes
- 2.5Gigabit Ethernet
- Yes
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11 a/b/g/n/ax
- I/O Expansions
- Total Number of Expansion Slots
- 5.0
- Total Number of PCI Express Slots
- 5
- Number of PCI Express x1 Slots
- 2
- Number of PCI Express x16 Slots
- 3
- Interfaces/Ports
- Total Number of USB Ports
- 8
- Number of USB 3.2 Ports
- 1
- Number of USB 3.2 Gen 1 Ports
- 4
- Number of USB 3.2 Gen 2 Type-A Ports
- 3
- S/PDIF
- Yes
- Number of Network (RJ-45) Ports
- 2
- Onboard Interfaces
- Number of SATA Interfaces
- 8
- Number of M.2 Interfaces
- 4
- Total Number of Onboard USB Ports
- 9
- Number of Onboard USB 2.0 Ports
- 4
- Number of Onboard USB 3.2 Ports
- 5
- Physical Characteristics
- Color Family
- Black
- Product Color
- Matte Black
- Form Factor
- Extended ATX
- Width
- 304.8 mm
- Depth
- 266.7 mm
- Miscellaneous
- Brand Compatibility
- Intel
- Environmentally Friendly
- Yes
- Energy Efficiency Compliance
- Energy-related Products Directive Ready (ErP Ready)
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- China Restriction of Hazardous Substances (China RoHS)
