Datalogic Gryphon GBT4500 Industrial, Retail, Healthcare, Transportation Handheld Barcode Scanner Kit - Wireless Connectivity - Black, White - USB Cable Included

  • Part: 1069937
  • Model: GBT4500-BK-BTK1HDD
£528.00

Availability

In Stock

  • General Information
    • Manufacturer
    • Datalogic S.p.A
    • Manufacturer Website Address
    • http://www.datalogic.com
    • Brand Name
    • Datalogic
    • Product Line
    • Gryphon
    • Product Series
    • 4500
    • Product Type
    • Barcode Scanner Kit

IMAGING TECHNOLOGY

The Gryphon 4500 series represents the premium range of hand held scanners from Datalogic for general purpose applications. Designed with people in mind, the Gryphon 4500 series stands out with its elegant and cutting edge design, the unchallenged ergonomics, and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.

WIRELESS COMMUNICATIONS

Featuring Bluetooth wireless technology (GBT model) or narrow band radio communications with Datalogic's STAR Cordless System (GM model), the Gryphon 4500 wireless readers provide maximum flexibility to solve any end user application with the best technical solution.

WIRELESS CHARGING

One of the most important technical innovations that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, which enhances the reliability of the entire solution, lowering the total cost of ownership because it eliminates the need for contacts' cleaning and maintenance procedures. The maximum reliability offered by the Gryphon wireless charging technology means 24/7 activities with no stops for maintenance or repair and top-level operating productivity and performance.

SIMPLE TO USE AND DEPLOY

The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes. High Density (HD) models are available for reading smaller, condensed codes as well as a dedicated version with red illumination optics to support Digital Watermarking. Datalogic's Motionix motion-sensing technology enables the scanner to intuitively switch into hand held mode when the device is picked up. When placed back into the stand, it seamlessly returns to stand mode. The adjustable position cradle provides the flexibility to use the scanner in presentation or stand mode while it's charging.

  • Warranty
    • Limited Warranty
    • 3 Year

  • Technical Information
    • Connectivity Technology
    • Wireless
    • Scanning Capability
    • 1D
    • 2D
    • Barcode Symbology Supported
    • 1D:
      • Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
      2D:
      • Aztec Code
      • China Han Xin Code
      • Data Matrix
      • MaxiCode
      • Micro QR Code
      • QR Code
      Postal codes:
      • Australian Post
      • British Post
      • China Post
      • IMB
      • Japanese Post
      • KIX Post
      • Planet Code
      • Postnet
      • Royal Mail Code (RM4SCC)
      Stacked codes:
      • EAN/JAN Composites
      • GS1 DataBar Composites
      • GS1 DataBar Expanded Stacked
      • GS1 DataBar Stacked
      • GS1 DataBar Stacked Omnidirectional
      • MacroPDF
      • MicroPDF417
      • PDF417
      • UPC A/E Composites
      Digital Watermarking:
      • Digimarc Barcodes
    • Light Source
    • Laser
    • Image Sensor Type
    • Imager
    • Depth of Field
      • 5.0 to 15.0 cm / 2.0 to 5.9 in @ Code 39
      • 0.5 to 25.0 cm / 0.2 to 9.8 in @ Code 39
      • 2.0 to 27.0 cm / 0.8 to 10.6 in @ Data Matrix
      • 2.0 to 23.5 cm / 0.8 to 9.3 in @ Data Matrix
      • 1.0 to 40.0 cm / 0.4 to 15.7 in @ EAN-13
      • 3.0 to 12.0 cm / 1.2 to 4.7 in @ EAN-13
      • 0.5 to 31.0 cm / 0.2 to 12.2 in @ PDF417
      • 2.0 to 25.0 cm / 0.8 to 9.8 in @ PDF417
    • Scan Pattern
    • Area
    • Omni-directional
    • Scanner Range
    • High Density
    • Scanning Distance
    • 398.78 mm
    • Features
    • Beep
    • Vibration
    • Notification LED
    • Cable Type Included
    • USB
    • Reading Angle (Skew)
    • 65°
    • Reading Angle (Pitch)
    • 65°
    • Reading Angle (Roll)
    • 360°
    • Motion Tolerance
    • 889 mm/s
    • Image Formats
    • BMP
    • JPEG
    • TIFF
    • Maximum Ambient Light
    • 100000 lux
    • Drop Specification
      • 3Withstands repeated drops from 1.8 m / 6.0 ft onto a concrete surface.
    • Minimum Print Contrast
    • 15%
    • Minimum Element Resolution (Code 39)
    • 0.08 mm
    • Maximum Element Resolution (Code 39)
    • 0.13 mm
    • Minimum Element Resolution (DataMatrix)
    • 0.13 mm
    • Maximum Element Resolution (DataMatrix)
    • 0.25 mm
    • Minimum Element Resolution (PDF417)
    • 0.10 mm
    • Maximum Element Resolution (PDF417)
    • 0.25 mm
    • Image Sensor Resolution
    • 1280 x 800
    • Illumination Type
    • LED
    • Illumination Color
    • White
    • Air Electrostatic Discharge (+/-)
    • 16kV
  • Network & Communication
    • Bluetooth
    • Yes
    • Radio Frequency
    • Yes
  • Interfaces/Ports
    • Host Interface
    • USB
    • Serial
    • Keyboard Wedge
  • Battery Information
    • Battery Capacity
    • 3250 mAh
    • Maximum Battery Recharge Time
    • 4 Hour
  • Environmental Conditions
    • Operating Temperature
    • 0°C to 50°C
    • Storage Temperature
    • -40°C to 70°C
    • Humidity (Non-condensing)
    • 0% to 95%
  • Physical Characteristics
    • Form Factor
    • Handheld
    • Color Family
    • Dual Colour
    • Product Color
    • Black
    • White
    • Durability
    • Water Resistant
    • Dust Resistant
    • Weight (Approximate)
    • 235 g
  • Miscellaneous
    • Package Contents
      • 1 x Gryphon 4500 GBT4500 Barcode Scanner
      • 1 x WLC4090-BK-BT-DRA base
      • 1 x USB Cable 90A052258
    • Ingress Protection (IP) Rating
    • IP52
    • Application/Usage
    • Industrial
    • Retail
    • Healthcare
    • Transportation
    • Manufacturing
    • Commercial Service
    • Environmentally Friendly
    • Yes
    • Environmental Compliance
    • China Restriction of Hazardous Substances (China RoHS)
    • Restriction of Hazardous Substances (RoHS)
