- General Information
- Manufacturer
- Manhattan
- Manufacturer Website Address
- http://www.manhattan-products.com
- Brand Name
- Manhattan
- Product Type
- Data Transfer Cable
Easily connect serial devices through a USB port.
Most modern computers and laptops don't have RS232 (DB9) ports, making the use of legacy peripherals and high-tech devices which connect with COM ports almost impossible. The Manhattan USB to Serial Converter - with its serial RS232 (DB9) port and Prolific PL-2303RA chipset - easily expands a single USB port to connect and support serial modems, barcode scanners, digital cameras, card readers, Ham/Amateur Radios, GPS, CNC machines, telescopes, embroidery machines, fuel injection controllers, PDUs, network switches and other devices.
Quality Construction and Easy Installation
Gold-plated contacts and rugged construction combine to offer a reliable connection between the computer and serial peripherals for consistent, trouble-free performance. Windows compatibility with plug-and-play installation and hot-swappability help provide seamless use without inconvenient and frustrating device conflicts.
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Cable Type
- Serial/USB
- Cable Length
- 45 cm
- Connector Type on First End
- DB-9 RS-232 Serial - Male
- Connector on First End Details
- 1 x 9-pin DB-9 RS-232 Serial - Male
- Connector Type on Second End
- USB 1.1 Type A - Male
- Connector on Second End Details
- 1 x USB 1.1 Type A - Male
- Contact Plating
- Gold
- Conductor
- Copper
- Device Supported
- Modem
- Digital Camera
- Label/Receipt Printer
- Card Reader
- Bar Code Reader
- Handheld Terminal
- Electronic Organizer
- Scanner
- PDU
- Network Switch
- Telescope
- Embroidery Machine
- Fuel Injection Controller
- American Wire Gauge
- 24 AWG
- Data Transfer Rate
- 115 kbit/s
- Features
- Plug & Play
- Hot-swappable
- Physical Characteristics
- Product Color
- Black/Silver
- Weight (Approximate)
- 164.4 g
- Miscellaneous
- Package Contents
- USB to Serial Converter
- Instructions and driver CD
- Environmentally Friendly
- Yes
- Environmental Certification
- RoHS
- WEEE
