Trusted and Reliable Printer of Choice | The TSP143III is a fast, easy and reliable POS printing solution.
Already a leading player in the POS and mPOS markets, the Star Micronics TSP143III thermal receipt printer offers WLAN, LAN, Bluetooth, or USB interface connectivity for an easy-to-use and ready-to-go installation. This trusted and reliable printer has a web configuration page for the WLAN and LAN TSP143III models and a simpler way for all devices to connect to the WLAN printer for setup with AP mode. It also features an easy Bluetooth pairing connection and a "plug and play" USB Lightning connection making installation effortless. The USB model has a USB serial number feature, so the PC will detect the TSP143IIIU on its Windows platform using any USB port.The TSP143III is an upgrade of the previous TSP100, printing at almost twice the speed with unique Print Flat Technology. It is fully compatible with its previous version, requiring no additional integration or development. With included internal power supply, power cables, complete mounting kits, and start-up paper roll, the TSP143III is the perfect printer for any mPOS bundle. Furthermore, Star has added an additional USB type A connector for one convenient power source for your tablet or mobile device. The TSP143III offers a small form factor for any sized counter space and prints up to 250 millimeters per second. The highspeed thermal printer also includes a guillotine auto-cutter and "drop-in and print" paper loading for even the busiest retail and hospitality environments.
- General Information
- Manufacturer
- Star Micronics, Inc
- Manufacturer Website Address
- http://www.starmicronics.com
- Brand Name
- Star Micronics
- Product Series
- TSP100III
- Product Type
- Direct Thermal Printer
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Recommended Use
- Receipt Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 250 mm/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Width
- 72 mm (2.83")
- Barcode Symbology Supported
- PDF417
- Maxi Code
- Application/Usage
- Desktop
- Mean Cycles Between Failures (MCBF)
- 60000000
- Print Head Life
- 100km
- Print Technology
- Direct Thermal
- Network & Communication
- Bluetooth
- Yes
- Cutter
- Cutter
- Yes
- Cutting Method
- Automatic
- Cutter Type
- Guillotine
- Cutter Life
- 2000000 Cuts
- Media Types & Handling
- Media Type
- Receipt
- Media Sensor
- Cover Open Sensor
- Maximum Roll Diameter
- 83 mm
- Maximum Label Width
- 80 mm
- Software
- Operating System Supported
Windows
- Power Description
- Power Source
- AC Supply
- Frequency
- 50 Hz
- 60 Hz
- Environmental Conditions
- Operating Temperature
- 5°C - 45°C
- Operating Relative Humidity
- 10% - 90%
- Storage Temperature
- 60°C
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Form Factor
- Wall Mount
- Color Family
- Grey
- Product Color
- Grey
- Height
- 132 mm
- Width
- 142 mm
- Depth
- 204 mm
- Weight (Approximate)
- 1.53 kg
- Miscellaneous
- Package Contents
- TSP143IIIBI2 Direct Thermal Printer
- Wall Mount Bracket
- Installation CD with Drivers and futurePRNT
- 58mm Paper Guide
- 6ft Interface Cable
- 6ft Power Cable
- Power Switch Cover
- Easy Setup Guide
- Compatibility
- iOS
- Android
- PC
- Platform Supported
- PC
- iOS
- Android
- Certifications & Standards
- UL
- C-UL
- TuV
- FCC
- VCCI
- EN55022
- CE
- Energy Star
- Yes
