- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertivco.com
- Brand Name
- Vertiv Liebert
- Product Series
- GXT5
- Product Type
- Double Conversion Online UPS
The Liebert GXT5 UPS in an on-line double conversion USP solution which offers premium power outage protection and continuous power conditioning in a compact and flexible deployment system. This single phase UPS operates with a high power efficiency and it is ideally suited to protect critical infrastructure in both centralized and edge of network applications.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Plug/Connector Type
- IEC 60320 C14
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 8 x IEC 60320 C13
- Overload Protection
- Yes
- Phase
- Single Phase
- Application/Usage
- Critical System
- Power Description
- Load Capacity (VA)
- 1 kVA
- Load Capacity (Watt)
- 1 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 115 V AC - 288 V AC
- Output Voltage
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- 200 V AC
- Input Frequency
- 70 Hz
- Waveform Type
- Pure Sine Wave
- Circuit Breaker
- Yes
- Management
- Network Management
- SNMP/HTTP Remote Monitoring
- Alarm
- Yes
- Controls/Indicators
- Status Indicators
- Colored Graphic LCD Display
- Interfaces/Ports
- Serial Port
- Yes
- VGA
- No
- Network (RJ-45)
- Yes
- USB
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Number of Batteries
- 3
- Battery Characteristics
- Valve-regulated, Non-spillable
- Battery Chemistry
- Lead Acid
- Battery Size
- 12V
- Battery Capacity
- 9000 mAh
- Backup/Run Time (Full Load)
- 6 Minute
- Backup/Run Time (Half Load)
- 15 Minute
- Battery Life
- 5 Year
- Typical Battery Recharge Time
- 3 Hour
- Hot Swappable
- Yes
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Storage Temperature
- -20°C - 60°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 15 km
- Storage Relative Humidity
- 0% - 95%
- Sound Emission
- 46 dB
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 85 mm
- Width
- 430 mm
- Depth
- 400 mm
- Rack Height
- 2U
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 16.50 kg
- Miscellaneous
- Software Included
- Power Insight 2.2
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS) 2
